GCA121.1E servomotor rotativ Siemens
Descriere
Servomotor rotativ al clapetei de aer, AC/DC 24 V, 2 poziții, 18 Nm, revenire cu arc 90/15 s
Torque 18 Nm
Air damper area 3 m²
Angular rotation 90°
Power consumption 7 VA, 5 W
Positioning time Open:90 s, Close:15 s
Cable length 0.9 m
Positioning signal 2-position
Spring return function Yes
Degree of protection IP54
Ambient temperature, operation -32…55 °C
Medium temperature -32…55 °C
Ambient humidity, operation 95 % r.h.
Dimensions (W x H x D) 100 x 313 x 71 mm
Operating voltage AC/DC 24 V
Auxiliary switch 0
Detalii produs
Cod produs - SKU
GCA121.1E
Categorie
Greutate produs
2 kg.
Producator
Fisa tehnica
